Forward Looking Acoustic and Infrared Imaging Technologies
FLaiTek iGo5 Thermal Camera Entry-Level
$1,499.00
FLaiTek iGo Series - Just Go! Simple Thermal Power!
Introducing the FLaiTek iGo5: a revolutionary entry-level thermal imaging camera that transforms your professional toolkit. Designed for applications such as home and building inspections, electrical diagnostics, and HVAC maintenance, the iGo5 is your dependable partner in detecting and analyzing temperature variations with precision.
Key Features:
High-Resolution Imaging: Equipped with a 384×288 infrared sensor, the iGo5 delivers detailed thermal images, enabling you to identify issues swiftly and accurately.
Exceptional Thermal Sensitivity: With a thermal sensitivity of 40mK, the iGo5 can detect minute temperature differences, crucial for pinpointing inefficiencies and potential problems.
Durable and Resilient: Built to withstand challenging environments, the iGo5 is dust and water-resistant, ensuring reliable performance in various conditions.
Versatile Lens with Manual Focus: Featuring a 49° x 36.8° wide-angle lens and optional manual focus, the iGo5 captures comprehensive thermal images, facilitating thorough inspections.
Elevate your thermal imaging capabilities with the FLaiTek iGo5—where advanced technology meets user-friendly design to enhance your professional efficiency.
Quantity
Lead time 8 weeks.
Key Specifications
| Key Features | FLaiTek iGo5 Thermal Imager |
| IR Resolution(SR) | 384*288 |
| Thermal Sensitivity（NETD) | 40mk(0.04°C)@30°C |
|
Lens /Field of View |
49°x 37° |
| Focus Mode | Focus free |
| Frame Rate | 40Hz |
| Build-in digital camera | 8 MP industrial camera |
| Image Modes | Thermal Image Mode, Visible Light Mode, Picture in Picture Mode, T-DEF (Image Fusion) Mode |
| Temperature Range | -20 °C to 550°C |
| Measurement Accuracy | ±2 °C or 2% , whichever is greater (at 25 °C ambient temperature） |
| Measurement Tools | Spot：6 Line：3 Rectangle/Circle：4 |
| Display Screen | 3.5 inch Touch Screen |
| Palettes | 8 Palettes，8 Inverted Palettes |
| Storage Card | TF card, 32GB, expandable to 128GB |
| On Device Analysis | Support |
| Voice & Text Annotation | Support (120 seconds for voice annotation) |
| Remote Display (with AnalyzIR Software) |
Support |
| Battery | Rechargeable Li-ion, 3.6V, 5000mAh |
| Battery operation time | ≥4 hours |
| Operation temperature | -20°C to 50°C |
| Storage temperature | -40°C to 70°C， without battery |
| Drop |
2m(GB/T 2423.8/IEC 60068-2-32)
|
| Weight ( include battery) | 800g |
| Enclosure rating | IP54 |
| Warranty | 2 years |
